APSmart Rapid Shutdown RSD-D-446101 Next Day Delivery

APSmart RSD-D-446101

Manufacturer’s part number: 446101

RSD-D (duo) PLC, 20A, 1500V UL/1000V TUV, 0.5m input cables / 2.2m output cables, MC4 DC connectors, Mounting brackets, IP68.

• Range of Input Operating Voltage: 8-65 Volts per channel
• Maximum Continuous Input Current (Imax): 20 Amps per channel
• Maximum Short Circuit Current (Isc): 25 Amps
• Range of Output Operating Voltage: 16-130 Volts
• Maximum Cont. Output Current: 20 Amps
• Maximum System Voltage: 1000V/1500V
• Enclosure Rating: NEMA Type 6P/IP68
