Description
Automaxx Marine Wind Turbine Generator Kit Bundle Set
Description
Go Green, Live Green
✅ 【Lightweight, Durable & Marine Approved Design】Our turbine blends lightweight construction with remarkable durability, tailored for marine excellence.
✅ 【Efficient Power】Generate 400W of 12V DC power even at low 6.7mph winds. Versatile for marine, home, farm, and off-grid use.
✅ 【Eco-Friendly】Harness wind for clean energy, reduce emissions, and lower bills.
✅ 【Optimized Control】MPPT controller maximizes battery charging efficiency. Safety features for worry-free operation.
✅ 【Simple Setup & Maintenance】Simple setup, minimal maintenance required—periodic inspection and lubrication suffices.
? Please note,our appisexclusive totheBluetooth editionmodels and is not compatible with other versions
- Additional waterproofing coating fused on all the parts
- Strengthened UV coating layered apple for additional protection
- The 400W wind turbine was designed with space saving in mind (Homes, parks, farms etc…)
- Easy 1 person installation, takes less than an hour to set up (minimal installation cost)
- Less than 22lbs once fully installed (can be easily carried by 1 adult)
- MPPT controller maximizes battery charging efficiency. Safety features for worry-free operation.
- Customizing our wind turbine for maximum electrical generating output
- Automaxx Marine wind turbine is Made in Taiwan and delivers up to 15% more in electric generating performance
- 3m/s cut-in speed means your battery is being charged even when stationary
- System reaches 80% of full output at just 20 kts
- Made with infused fibreglass to obtain high durability and lightweight property
- 3 pillars of Automaxx’s combination of lightweight durable fiberglass infused blades, 3-phase permanent magnet synchronous AC generator and built in charge controller equals to incredible performance
Discover more through your phone: Keep Track of Watt’s Important (Bluetooth version only)
- Free to download (iOS and Android)
- Live Wattage and Amperage readings
- View Total Wattage generated
- Switch control for braking system
Easy DIY installation setup: All the tools needed for setup is provided
- We provide you with all the nuts, bolts and tools you need to set up your wind turbine correctly
- Standard 48,3 mm pole is used to mount the wind turbine (purchase for normal hardware store)
- 7 easy steps for installation
- Easy to operate
| PRODUCTS INCLUDES |
| 3 x Turbine |
| 9 x Blades |
| 3 x Nose Cone |
| 3 x Amp Meter |
| 3 x Brake Switch (Manual Stop Switch) |
| 9 x Spare Blades |
| 3 x Spare Nose Cone |
| 3 x Accessory Pack |
Product Specifications
Automaxx Marine Wind Turbine Generator Kit Bundle Set Product Specifications
| Max. Output Power | 400W |
|---|---|
| Rated Speed | 28 mph/ 12.5 m/s |
| Diameter of Mounting Hub | 1.9 inches |
| Generator Type | Permanent Magnet Brushless |
| Rated Load Current | 25A |
| Recommended Battery Capacity | 100A/hr |
| Weight | 22 lb |
| Blade Material | Nylon + Glass Fiber |
| Output Voltage | 0-15V |
| Cut-In Wind Speed | 6.7mph / 3m/s |
| Spinning Diameter | 4ft / 1.22m |
| Battery Protection Voltage | 14.7V |
| Charging Efficiency | ≥ 90% |
| Over Speed Braking | ≤ 1200RPM |
Product Manual
Automaxx Marine Wind Turbine Generator Kit Bundle Set Manual
Product Warranty & Return
Automaxx Warranty & Return
General
We warrant your product to be free from defects in material and/or workmanship for 2 year from the original date of purchase. Warranty coverage is extended only to the customer (original purchaser). If the product proves defective during the warranty period, Automaxx option will be:
- Replace wind turbines with a new or refurbished product.
- Repair or replace the defective part.
The customer’s warranty continues to be valid on repaired or replaced products from the original warranty date.
Warranty Period
The Automaxx warranty valid for the period of two year (730 days) after the date of first purchase. If proof of purchase cannot be provided, the manufacturer date as recorded by Automaxx will be deemed to be the start of the Warranty Period.730
What is covered and what’s not?
All Automaxx products and accessories that are purchased from Automaxx website are covered for two year.
The warranty covers defects in manufacturing discovered while using the product as recommended by the manufacturer. The warranty does not apply to
- Product, equipment, or accessories that not purchased from the Automaxx.
- Product that has been tampered with, repaired, modified or altered other than by manufacturer or without prior
- manufacturer’s approval.
- Damage to the Product caused by windstorms (upwards of Beaufort Wind Scale 7), lightning and Hail damage.
- Damage to the Product caused by improper installation, negligence, accidents damage, misuse, or abuse.
- The serial number of the Product, components or accessories has been altered or removed.
- The Warranty seals have been broken or altered.
- Fraud, theft, unexplained disappearance, or damages / detrimental circumstances caused by an willful act of the customer.
- All acts of God
Any service identified in the above list or product is found not to have any defect in manufacturers’ workmanship or materials the customer will be responsible for the costs of all repairs and expenses incurred by the manufacturer.
If the Product is under Warranty, You hereby agree to transfer the ownership of replaced defective parts/ accessories and such parts shall automatically become the property of Automaxx and returned to Automaxx for inspection.
